Package libavg :: Module avg :: Class VectorNode

Class VectorNode

Instance Methods

setBitmap(bitmap)
Sets a bitmap to use as a texture.

Inherited from unreachable.instance: __new__

Inherited from object: __delattr__, __getattribute__, __reduce__, __reduce_ex__, __repr__, __setattr__, __str__

Inherited from Node

__eq__(...)

__hash__(...)
hash(x)

__init__(...)
Raises an exception This class cannot be instantiated from Python

__ne__(...)

abspos

getAbsPos(relpos)
Transforms a position in coordinates relative to the node to a position in window coordinates.

node

getParent()
Returns the container (AVGNode or DivNode) the node is in.

relpos

getRelPos(abspos)
Transforms a position in window coordinates to a position in coordinates relative to the node.

releaseEventCapture(cursorid)
Restores normal mouse operation after a call to setEventCapture().

setEventCapture(cursorid)
Sets up event capturing so that cursor events are sent to this node regardless of the cursor position.

setEventHandler(type, source, pyfunc)
Sets a callback function that is invoked whenever an event of the specified type from the specified source occurs.

None

unlink(kill)
Removes a node from it's parent container.

Inherited from Node
Properties
	blendmode The method of compositing the node with the nodes under it.
	color The color of the strokes in standard html color notation: FF0000 is red, 00FF00 green, etc.
	strokewidth The width of the strokes in the vector.
	texhref An image file to use as a texture for the node.
Inherited from `object`: `__class__`
	active If this attribute is true, the node behaves as usual.
	id A unique identifier that can be used to reference the node.
	opacity A measure of the node's transparency.
	sensitive A node only reacts to events if sensitive is true.

Method Details

setBitmap(bitmap)

Sets a bitmap to use as a texture. Sets texhref to an empty string.

Parameters:

bitmap - A libavg bitmap object to use.

Property Details

blendmode

The method of compositing the node with the nodes under it. Valid values are 'blend', 'add', 'min' and 'max'.

Get Method:: unreachable(...)
Set Method:: unreachable(...)

color

The color of the strokes in standard html color notation: FF0000 is red, 00FF00 green, etc.

Get Method:: unreachable(...)
Set Method:: unreachable(...)

strokewidth

The width of the strokes in the vector. For lines, this is the line width. For rectangles, it is the width of the outline, etc.

Get Method:: unreachable(...)
Set Method:: unreachable(...)

texhref

An image file to use as a texture for the node.

Get Method:: unreachable(...)
Set Method:: unreachable(...)
